Standard data and equipment: single phase 220V/50Hz, Brass impeller, or Nylon impeller, carbon steel motor shaft.
Other model and material such as three phase,110V,60Hz, dual voltage, stainless steel shaft, etc, will be avallable upon request.
TECHNICAL DATA
TYPE | Power | H.max (m) |
Q.max (L/min) |
Size (inch) |
S.Head (m) |
G.W (kg) |
Packing QTY. |
|
KW | HP | |||||||
JET60S | 0.37 | 0.55 | 35 | 40 | 1"X1" | 9 | 10 | 1700 |
JET80S | 0.55 | 0.75 | 44 | 50 | 1"X1" | 9 | 11 | 1600 |
JET100S | 0.75 | 1 | 48 | 60 | 1"X1" | 9 | 12 | 1600 |
